Product introduction:
Stone washing machine is the mechanical equipment cleaning of stone materials, in order to ensure the engineering quality requirements and ensure that there is sufficient productivity to meet the concrete mixing station supplies the stone.
Working principle:
The working process is generally as follows: raw material storage, transportation, cleaning, finished product transportation, sewage precipitation and reuse;
Storage of raw materials generally storage hopper, the storage hopper requirements can be used for ZL50 loader loader, bucket mouth feeding width should be greater than 3 meters, hopper capacity depending on the loading machine material transportation height and height, raw material self angle and so on, the bigger is better.
The raw material conveying generally adopts the belt conveying, and the water content of the raw material is best to set the throttling device to control the amount of cleaning. Because of general quarrying field provides the raw stone attached to the dust and mud volume is small and the force is small, so the cleaning process does not need to be too long, the key is stone wash finished unloading not incidental trough visceral water, and the composition of the stone of the secondary pollution.
Complete stone cleaning but also through the general belt conveyor transported to the finished material storage area or storage hopper stand-by, so the best the repository shielding processing or now wash with. Regardless of which type of stone washing machine will produce large amounts of sewage and water is almost the same, considering environmental requirements generally set up sewage precipitation recycling pool, depending on the output to determine the water volume and precipitation levels considered in conjunction with the sludge mechanical or manual cleaning.
